Ribbon Wire Cutting Machine

Ribbon Wire Cutting Machine Ribbon Wire Cutting Machine

Ribbon Wire Cutting Machine

Product Description

Model: TM-HS-330

Features

  • Suitable for cutting, head-stripping, middle-stripping and tail-stripping of single-strand and multi-strand wire
  • Can process wires in such industries as electronic products, electric appliance, toys and auto motorcycle parts, etc.
  • With a microcomputer-controlled very clean designed mechanism, it cuts and strips wire automatically.
  • Various cutting style and programmable length and distance can suit any wire assembly needed.

Specification

Model

TM-HS 330

Weight

32KG

Overall Dimension

420*290*255mm

Power

200-450W

Mode of Display

LCD Liquid Crystal Display Screen

Cutting Length

1mm-15000mm

Cutting Tolerance

≤0.002*L(Cutting Screen)

Stripping Length

HEAD 0-100mm,TAIL 0-80mm

Cutting the Cross-Sectional Area of Wire Core

0.2-16mm2

Maximum Diameter of Conduit Pipe

13

Middle-Stripping

13 Places of Stripping

Material Of Knife

Tungsten Steel

Stripping Speed

2000-5000PCS/H

Mode Of Driving

Four Wheeled Drive

Adjusting Speed

9 Slowest, 0 Fastest
