FEATURES:
| Model | TM-IM-21 Dies |
|---|---|
| Wire Input Size | Φ2.6-Φ3.0 mm |
| Wire Output Size | Φ0.4-Φ1.4 mm |
| Max. Speed | 1800 Mtr/min |
| Max. No of Dies | 21 |
| Elongation rate | 18.4%+15% |
| Machine Consutruction | Casting + Steel Welded and annealed |
| Drawing Capstan Type | Tungsten Carbide |
| Correction System | Automatic Digital control of Take Up |
| Annealing Current | 1200 Amp. |
| Lubricant Type | Lubrication by full immersion |
| Capstam Dia. | 250 mm |
| Main Motor Power | AC 55 kW |
| Take Up Loading Capacity | 200Kg (DIN 500) or 500Kg (DIN 630) |
| Power Source | 415V/AC50Hz |
| Brake Type | Air Disc Type |
| Net Weight | 6000 Kgs. Approx. |
