High Speed Power Cord Stripping Machine

High Speed Power Cord Cutting Stripping Machine Multi core cable cutting machine

High-Speed Power Cord Cutting Stripping Machine

Product Description

Model: TM-HS-280

Features

  • Suitable for cutting, head-stripping and tail-stripping of single-strand and multi-strand wire and sheath wire
  • The maximum processing cross-sectional area is 4-8mm2, the maximum cutting length is 9999mm, head-stripping 250mm and tail-stripping 50mm
  • This machine is suitable for stripping sheath wire especially for sheath wire of long wirehead and the Wire tail

Specification

Model TM-HS280
Weight 32KG
Overall Dimension 390*350*255mm
Power 200-450W
Mode of Display LCD LIQUID CRYSTAL DISPLAY SCREEN
Cutting Length 30mm-9999mm
Cutting Tolerance ≤0.002*L(CUTTING LENGTH)
Sheath Stripping Length HEAD 0.1-250mm,TAIL 0.1-50mm
Cutting the Cross-Sectional Area of Wire Core 4-8mm 2
Maximum Diameter of Conduit Pipe 11
Middle-Stripping 13 PLACES OF STRING
Material of Knife TUNGSTEN STEEL
Stripping Speed 4000-10000PCS/H
Mode of Driving FOUR-WHEELED DRIVE(EACH STEP 0.1mm FORWARD)
Adjusting Speed 0 SLOWEST, 9 FASTEST
