Coaxial Cable Stripping Machine

Coaxial Cable Stripping Machine coaxial cable stripping machine

Coaxial Cable Stripping Machine

Product Description

Model: TM- 4806

Mainly used for processing of coaxial cable and special single line, using the most advanced rotary tool carrier, improve the accuracy and speed. The specific axis positioning device and rotary cutting tool, up to 9 layers without changing the blade stripping process can correspond to various sizes and wires, and the equipment can be set free by the combined controller, digital display of the cutting wire

Features

Model

TM- 4806 coaxial wire stripping machine

Maximum Machining Cable Diameter

Up to 6.99 mm

Minimum Machining Cable Diameter

Up to 0.81mm

Cutting Depth Unit

0.01mm

Maximum Peeling Length

48mm

Maximum Peeling Layer

9 Layer

Drive Mode

motor / Ball Screw Driver

Display Mode

Touch Screen

Blade

2, Material: Imported Swiss Tungsten Steel

Clamping Device

Automatic Adjustment of the Heart, Motor Drive, Clamping Force Program Control

Efficiency

500-700 pcs/h(Line of Sight Type and Length of the Cable)

Open Mode

Manual / Sensor

Power Supply

220V/50Hz

Power

380W

Weight

19KG

Size

190X285X530 mm
